SoundOff nERGY 400 Series Console Siren - Knob, 1
Shipping Time: Approximately 3–4 weeks
Note: Custom-built to order — made after you place your order.
SoundOff nERGY 400 Series Console Siren – Knob Control (Amplifier Only)
The SoundOff nERGY 400 Series Console Siren with knob control provides precise, reliable siren management for emergency vehicles. This is an amplifier-only unit and does not include any speakers, allowing users to connect external speakers of their choice. Its rotary knob offers smooth, intuitive control, while the compact console-mounted design ensures easy integration into law enforcement, fire, or EMS vehicles.
⚠️ Speakers are NOT included. External speakers must be purchased separately.
Key Features
-
Amplifier-Only Single-Tone Output: Supports 100-watt operation when connected to external speakers.
-
Knob Control: Smooth rotary knob enables precise and intuitive tone selection.
-
Compact Console Design: Integrates amplifier and control panel in one unit for efficient installation.
-
Built-In Protections: Safeguards against over/under voltage, short circuit, and reverse polarity.
-
Hands-Free Operation: Cycle or cancel tones via the horn button (horn-ring circuit).
-
Relay Control: Manages up to 12 relay outputs (three 20-amp and nine 10-amp).
Specifications
-
Certifications: SAE J1849, CA Title 13 (with external speakers)
-
Input Voltage Range: 10–16 VDC
-
Power Output: 100 watts (single tone, requires external speaker)
-
Current Draw: 7 Amps @ 13.4 VDC (with external speaker)
-
Audio Frequency: 500Hz – 3kHz
-
Siren Frequency: 675Hz – 1633Hz
-
Operating Temperature: -40°C to +50°C
-
Dimensions:
-
Control Panel: 3.51” L x 6.98” H x 1.17” D
-
Amplifier: 6.62" L x 7” H x 6.51” D
-
Custom-Built Orders: SoundOff Signal products are custom-built to order. This means manufacturing begins after your order is placed.
Order Cancellation Policy: You have 24 hours from the time of purchase to request an order cancellation. After this 24-hour window, orders cannot be canceled because the custom manufacturing process may have already begun.
Shipping Time: Please allow approximately 3–4 weeks from the date your order is placed for shipment. We will ship your order as soon as it is ready and provide tracking information once it becomes available.
Return Policy: Returns require prior authorization from SoundOff Signal. Non-defective returns are subject to SoundOff Signal's approval. Original factory packaging is required. Custom-built orders are subject to the applicable return restrictions.
Request return assistance via email:
info@forgesafetypse.com
Warranty: Products will be repaired or replaced at SoundOff Signal's discretion, subject to the applicable warranty terms.
Cancellation or Return Requests: Please contact us at info@forgesafetypse.com within the applicable timeframe for assistance.
